| RACKED REMOTE CONTROL TRANSPORT VEHICLE |
| MODEL | ET4000-YS |
| DIMENSION(L*W*H) | 1215*785*640MM |
| NET WEIGHT | 175KG |
| DRAG WEIGHT | 300KG |
| MOTOR | PERMANENT MAGNET SYNCHRONOUS MOTOR |
| RATED POWER | 2000W*2 |
| MAX POWER | 4200W*2 |
| MAX TORQUE | 49N.M*2 |
| BATTERY | TERNARY POLYMER LITHIUM BATTERY |
| SPECIFICATION OF BATTERY | 72V45AH |
| CHARGER | 84V15A |
| CHARGING TIME | ≤3HOURS |
| CHARGING AMBIENT TEMPERATURE | 0℃ TO 50℃ |
| TRACK | DOUBLE RUBBER TRACK |
| SUSPENSION SYSTEM | ALUMINUM CASTING
CHRISTIE SUSPENSION |
| SHOCK ABSORBER | HYDRAULIC DAMPING *6 |
| MAX SPEED (FORWARD) | 22KM/H（6.1M/S） |
| MAX SPEED (BACK OFF) | 22KM/H（6.1M/S） |
| TURNING RADIUS | 0M |
| CLIMBING ABILITY (FORWARD ) | SLOPE ≥ 100% (ANGLE ≥ 45 °) |
| CLIMBING CAPACITY (LATERAL) | SLOPE ≥ 60% (ANGLE ≥ 31 °) |
| RANGE | ≥ 30KM (NORMAL TEMPERATURE @ AVERAGE 15KM / H) |
| DISCHARGE AMBIENT TEMPERATURE | -15 ℃ TO 60 ℃ |
| REMOTE CONTROL DISTANCE | WITH OBSTACLES: 300M
WITHOUT OBSTACLE: 600M |
| FR/RR LIGHTS | 10W*4 |
| APPLICABLE ENVIRONMENT | SNOW / SAND / MUD / MOUNTAIN / DEPRESSION / ROAD |
| SPECIFICATION OF FIRE FOAM/WATER MONITOR |
| RATED WORKING PRESSURE | 0.8MPA |
| WORKING PRESSURE RANGE | 0.5～1.0MPA |
| RATED FLOW | 50L/S |
| RANGE (ELEVATION 30 °) | WATER≥70M，FOAM≥65M |
| MAX. SPRAY ANGLE | 120° |
| PITCH ANGLE | 30°～70° |
| HORIZONTAL ROTATION ANGLE | ≥90° |
| POWER OF MOTOR | 24V |
| REMOTE CONTROL RADIUS | ≥150M |
| CONNECTION | Φ 80 MV CARD INTERFACE/ Φ 80 INTERNAL BUCKLE INTERFACE |
| SPECIFICATION OF REMOTE CONTROL'S SCREEN |
| SIZE | 7-INCH IPS LCD |
| DEFINITION | 1080P HD DIGITAL IMAGE TRANSMISSION |
| WORKING VOLTAGE | 4.2V |
| FREQUENCY BAND | 2.400-2.483GHZ |
| RF POWER | 0DB@CE / 23DB@FCC |
| FREQUENCY HOPPING | FHSS FREQUENCY HOPPING |
| NUMBER OF CHANNELS | 16 |
| LITHIUM BATTERY CAPACITY | 20000MAH |
| ENDURANCE | 6-20H |
l Fast speed, strong climbing ability, long remote control distance, flexible and can turn around in place.
l Equipped with 1080p HD camera, the remote control has a 7-inch large screen, which can monitor the real scene in real time.
l The fire monitor has its long range, and its body and barrel can be remotely controlled. The personnel can be remotely controlled away from the site, which can effectively keep the staff away from the source of danger.
l The fire monitor hss also equipped with manual control device, which can be operated manually when the power supply of the equipment is exhausted.
l Except with water, fire monitor can also spray foam mixture.
l Especially suitable for oil fields, oil depots, airports, wharfs, large buildings, petrochemical tank areas, narrow streets and buildings’ underground space that are difficult for fire engines to enter, and all kinds of toxic, harmful, flammable and explosive high-risk places.
l Has 2-channel water inlet pipe makes it more convenient for pipe road switching and continuous work.
l It is an indispensable basic equipment for fire safety supporting facilities.
